Building Material 500m Construction Elevator Lift Hoist With Inverter Control

Building Material 500m Construction Elevator Lift Hoist With Inverter Control

Brand Name:	TW-TECHWAY
Model Number:	SC270-270, SC300-300,SC270,SC300
MOQ:	1 Unit
Price:	18,800USD~80,000 USD per Unit
Payment Terms:	L/C, T/T
Supply Ability:	500 Units Per Month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Steel Pipe:

Q345B High Strength Steel

Rated Load:

2700kg/3000kg

Rated Speed:

0-63m/min

Max. Installation Hight:

500m

Max. Passenger No.:

Treatment:

Hot Dip Galvanization+Painting

Wall Panel:

Punched Aluminium Panel

Packaging Details:

Nude in Container, 40'HQ

Supply Ability:

500 Units Per Month

Highlight:

inverter control construction elevator lift

500m construction elevator lift

500m building material hoist

Product Description

Special designed Construction Elevator with rack and pinion/ inverter control type/ heavy loda capacity building hoist

Features:

With full experiences of special building hoists design & manufacturing, we cater to the special needs of our clients according to the project requests. The specially-designed hoists including following specifications:

Specifications:

CAGE TYPE	MODEL	RATED LOAD (KG)	SPEED(M/MIN)	SAFETY DEVIECE	MOTOR POWER (KW)
SINGLE CAGE	SC270	2700	0-46	SAJ50-1.2	3X11
	SC270	2700	0-63	SAJ60-2.0 rated trigger speed 1.4	3X11
	SC300	3000	0-46	SAJ50-1.2	3X11
	SC300	3000	0-63	SAJ60-2.0 rated trigger speed 1.4	3X11
	SC320	3200	0-63	SAJ60-2.0 rated trigger speed 1.4	3X18.5
DOUBLE CAGES	SC270/270	2700	0-46	SAJ50-1.2	2X3X11
	SC270/270	2700	0-63	SAJ60-2.0 rated trigger speed 1.4	2X3X11
	SC300/300	3000	0-46	SAJ50-1.2	2X3X11
	SC300/300	3000	0-63	SAJ60-2.0 rated trigger speed 1.4	2X3X11
	SC320/320	3200	0-63	SAJ60-2.0 rated trigger speed 1.4	2X3X18.5
