Material Transport Retractable Crane Loading Deck 3.2m Width MLP3200

China GUANGZHOU TECHWAY MACHINERY CORPORATION certification
China GUANGZHOU TECHWAY MACHINERY CORPORATION certification
TW is my very reliable partner for building hoist, we have been working with each other since year 2015, and I am very happy with their performance and support. Very glad they have newly opened the most advanced production facilities in China, and hope I could be there for their official ceremony once the COVID is over.

—— Lederberg Sha***

Their material loading bay is really fantastic, with their qualified products, now we are expanding our rental & sales business from Sydney to more cities in Australia.

—— Jay JAW***

I'm Online Chat Now

Material Transport Retractable Crane Loading Deck 3.2m Width MLP3200

Material Transport Retractable Crane Loading Deck 3.2m Width MLP3200
Material Transport Retractable Crane Loading Deck 3.2m Width MLP3200
video play

Large Image :  Material Transport Retractable Crane Loading Deck 3.2m Width MLP3200

Product Details:
Place of Origin: China
Brand Name: TECHWAY
Certification: Mill Certificate & Full-load Certificate
Model Number: MLP3200
Payment & Shipping Terms:
Minimum Order Quantity: 1 Unit
Price: USD9,200.00-10,300.00 per unit
Packaging Details: 2 Units in 1x20'GP, Nude in Container
Delivery Time: 40 Days after advance payment
Payment Terms: L/C, T/T
Supply Ability: 100 Units per month
Detailed Product Description
Painting: Sand Blasting & Epoxy Paint Treatment: Main Frame & Props Are With Hot Dip Galvanization
Platform Width: 3.2m Max. Load: 5000kg
Max. Outboard Length: 5.3m
High Light:

3.2m Width Safety Loading Platform

,

Material Transport Loading Dock Safety

,

Adjustable Props Crane Loading Platform

3.2m Width Retractable Or Solid Material Crane Deck MLP3200 For Material Transport At Construction Site





Crane Loading Deck Features

1. Easy pull/push system

2. Max. outboard length: 5.3m

3. Max. load capacity: 5ton

4. Platform width: 3.2m

5. With adjustable props for different floor heights

6. Compact design makes the transportation & installation much easier

7. With easy locking system

8. All pins are with chains to keep them from falling or losing



Forces on the Building or Structure
The deadweight and load of the load deck apply to the ceiling and the concrete slab by the support

props or the fixing anchoring bolts. The forces on the ceiling or the slab floor of the building can be provided.



When calculating the forces on the ceiling and floor from the load deck, we used following suppositions:

a) Assumed load always centered on deck;
b) Self weight of the loading platform is calculated according to the actual weight of the deck;
c) All loads are calculated by taking all actual loads and multiplying them by an impact factor 1.3;

d) All loads are working loads uniformly distributed on the floor deck of the platform (UDL);
e) Horizontal forces not taken into account;
f) Reactions provided based on rigid supports, i.e. - effects of deflections of supporting slabs not factored

into design.



Application

The Crane Loading Deck is specially designed for coping with the challenges of multi-story construction sites. Our crane loading decks make access for tools and materials to different levels of multi-story construction sites safe and simple, while increase the working efficiency of tower cranes.



Support Props Height
The standard props allow a minimum height of 2400mm and a maximum height of 3300mm.Consult

your dealer for other special requirements. We can design special props according to your requirements. Furthermore, MLP 2200-L, MLP 2200-H, MLP 2600,MLP 3200, MLP 4200 can also be fixed to the concrete slab with bolts through slab if the customer needs.





Application

The Crane Loading Deck is specially designed for coping with the challenges of multi-story construction sites. Our crane loading decks make access for tools and materials to different levels of multi-story construction sites safe and simple, while increase the working efficiency of tower cranes.



Function

MLP series retractable loading deck is a unique product to improve materials handling efficiency and safety for the multi-storey and high rise construction sectors. It offers a cost effective method of delivering goods to different
levels of a building when used with a crane. When goods are required to be delivered toa particular floor levels,
all the decks installed above that level can be retracted, enabling the crane to operate unobstructed.





Material Transport Retractable Crane Loading Deck 3.2m Width MLP3200 0



Material Transport Retractable Crane Loading Deck 3.2m Width MLP3200 1
