Low Speed SC120 Hoist Spare Parts 30kN SAJ Safety Device

China GUANGZHOU TECHWAY MACHINERY CORPORATION certification
China GUANGZHOU TECHWAY MACHINERY CORPORATION certification
TW is my very reliable partner for building hoist, we have been working with each other since year 2015, and I am very happy with their performance and support. Very glad they have newly opened the most advanced production facilities in China, and hope I could be there for their official ceremony once the COVID is over.

—— Lederberg Sha***

Their material loading bay is really fantastic, with their qualified products, now we are expanding our rental & sales business from Sydney to more cities in Australia.

—— Jay JAW***

I'm Online Chat Now

Low Speed SC120 Hoist Spare Parts 30kN SAJ Safety Device

Low Speed SC120 Hoist Spare Parts 30kN SAJ Safety Device
Low Speed SC120 Hoist Spare Parts 30kN SAJ Safety Device Low Speed SC120 Hoist Spare Parts 30kN SAJ Safety Device

Large Image :  Low Speed SC120 Hoist Spare Parts 30kN SAJ Safety Device

Product Details:
Place of Origin: China
Certification: CCC,CE
Model Number: SAJ30-1.2
Payment & Shipping Terms:
Minimum Order Quantity: 1Unit
Price: Negotiable
Packaging Details: Paper Box in Container
Delivery Time: 15 Days after advance payment
Payment Terms: L/C, T/T
Supply Ability: 1000 Units Per Month
Detailed Product Description
Trigger Speed: 1.2m/s Max. Brake Load: 30 KN
Expire Date: 5years
High Light:

30kN SAJ Safety Device

,

SC120 Hoist Spare Parts

Building Hoist Parts SRIBS SAJ Safety Device 30kN for Low Speed SC120 Building Hoist/Construction Elevator



Safety Device for Buidling Hoist/Conctruction Elevator



SAJ safety device is compulsory part on the building hoist/construction in China. When the building hoist/construction elevator descends over the rated speed, the micro-switch inside the safety device will be activated to cut off the power of the building hoist/construction elevator. Together with the brake of the motors, the safety device's pinion stops the cart of building hoist/construction elevator's cart onto the mast section gradually, which is very critical to the safety system of the building hoist.



The life span of the SAJ series safety device is five (5) years, and it has to be tested every six (6) months after the first test during the installation of building hoist/construction elevator.



Specifications



Model Trigger speed Max. Brake Load Expire Date
SAJ30-1.2 1.2m/s 30 kN 5years
SAJ30-1.4 1.4m/s 30 kN 5years
SAJ40-1.2 1.2m/s 40 kN 5years
SAJ40-1.4 1.4m/s 40 kN 5years
SAJ40-2.0 2.0m/s 40 kN 5years
SAJ50-1.4 1.4m/s 50kN 5years
SAJ50-2.0 1.4m/s 50kN 5years
SAJ60-2.0 1.4m/s 60kN 5years
SAJ65-2.0 2.0m/s 65kN 5years

























Low Speed SC120 Hoist Spare Parts 30kN SAJ Safety Device 0



Low Speed SC120 Hoist Spare Parts 30kN SAJ Safety Device 1



Low Speed SC120 Hoist Spare Parts 30kN SAJ Safety Device 2

Low Speed SC120 Hoist Spare Parts 30kN SAJ Safety Device 3
